Revolutionize Digital Advertising with an 85 Inch Eye Tracking Naked Eye 3D Display
The 85 Inch Eye Tracking 4K Naked Eye 3D Digital Advertising Billboard Display is a next-generation commercial display solution designed to create immersive visual experiences without requiring viewers to wear special glasses.
Combining advanced Eye Tracking Technology, 4K Ultra HD Resolution, and Autostereoscopic 3D Imaging, this powerful display delivers realistic depth, vivid visuals, and exceptional audience engagement for premium advertising and brand communication.
As a professional Naked Eye 3D Display Manufacturer, ZXTLCD provides factory-direct solutions with comprehensive OEM and ODM customization services for global distributors, advertising companies, and commercial display integrators.
Stunning 4K UHD Visual Quality
Featuring a commercial-grade 85-inch LCD panel with 3840 × 2160 resolution, this display provides exceptional image clarity and detail.
Display features include:
- 4K Ultra HD resolution
- High brightness commercial panel
- Wide 178° viewing angle
- High contrast ratio
- Accurate color reproduction
- Smooth video playback
- Industrial-grade reliability
Large-format 85-inch glasses-free 3D displays are widely used for premium commercial applications because they combine large visual impact with high-resolution content delivery.
| 85-inch Glasses-free 3D Display | ||
| Display Panel | Panel Size | 85 Inch |
| Backlight Type | Direct‑Lit LED Array | |
| Resolution | 3840 × 2160 (4K UHD) | |
| Active Display Area | 1872 × 1053 mm | |
| Brightness | 450 cd/m² | |
| Contrast Ratio | 3000:1 | |
| Viewing Angle | 178° (89°/89°/89°/89°) | |
| Refresh Rate | 60 Hz | |
| Response Time | 8 ms | |
| Color Depth | 1.07 Billion Colors | |
| Aspect Ratio | 16:9 | |
| Glasses‑Free 3D Performance | 3D Technology | Lenticular Lens Autostereoscopic |
| Supported 3D Formats | Multi‑view, Side‑by‑Side (SBS), Top‑and‑Bottom (TAB), 2D+Depth (2D+Z) | |
| Number of Viewpoints | 56 Views | |
| Light Transmittance | 95% | |
| Optimal Viewing Distance | 2.5m – 8m (Adjustable) | |
| Optimal Viewing Angle | 150° Horizontal | |
| 3D Display Mode | Multi‑view Glasses‑Free 3D | |
| Mechanical Specifications | Active Display Area | 1872 × 1053 mm |
| Packing Dimensions | 2090 × 250 × 1310 mm | |
| Net Weight | 180 kg | |
| Gross Weight | 200 kg | |
| Installation Options | Wall Mounted / Mobile Stand | |
| Electrical Specifications | Input Voltage | AC 100‑240V, 50/60Hz |
| Maximum Power Consumption | 450W | |
| Operating Mode | 24/7 Commercial Use | |
| Environmental Conditions | Operating Temperature | 0°C ~ 40°C |
| Operating Humidity | 20% ~ 80% RH (Non‑condensing) | |
| Storage Temperature | -5°C ~ 45°C | |
| Storage Humidity | 20% ~ 90% RH (Non‑condensing) | |
| Service Life | 50,000 Hours | |
| Standard Monitor Version – Display Controller | Operating System | None |
| Signal Processing | Professional 4K Display Controller | |
| Signal Output | V‑BY‑ONE Point‑to‑Point Transmission | |
| Maximum Resolution | 4K @ 60Hz | |
| Standard Monitor Version – Interfaces & Compatibility | HDMI Input | 2 × HDMI 2.0 |
| Supported Resolution (HDMI) | 2K@60Hz / 4K@60Hz | |
| USB | 1 × USB (Debug) | |
| Audio Output | Stereo Audio Output | |
| Built‑in Speakers | 2 × 5W Speakers | |
| Windows PC Compatibility | Supported | |
| Android Media Player Compatibility | Supported | |
| Desktop VR Workstation Compatibility | Supported | |
| External 3D Server Compatibility | Supported | |
| Android 7.1 Version (Optional) – System & Hardware | Operating System | Android 7.1 |
| CPU | RK3399 Hexa‑Core | |
| CPU Architecture | Dual Cortex‑A72 + Quad Cortex‑A53 | |
| CPU Frequency | Up to 2.0GHz | |
| MCU | Integrated Cortex‑M0 | |
| GPU | ARM Mali‑T860MP4 | |
| RAM | 2GB Standard (4GB Optional) | |
| Storage | 16GB Standard (32GB / 64GB Optional) | |
| EEPROM | 32KB | |
| Android 7.1 Version (Optional) – Interfaces & Network | USB | 2 × USB 3.0 + 1 × USB 2.0 Host + 5 × USB |
| HDMI | 1 × HDMI 2.0 (4K@60Hz) | |
| GPIO | 4 Channels | |
| RS232 | 3 Ports | |
| RS485 | 1 Port | |
| TTL | 1 Port | |
| Debug Port | 1 Port | |
| Audio Output | Stereo Output | |
| Wi‑Fi | Dual‑Band Wi‑Fi | |
| Bluetooth | BT 4.0 (Optional) | |
| Ethernet | 10/100/1000 Mbps RJ45 | |
| Cellular | Optional 3G / 4G Module | |
| Android 5.1 Version (Optional) – System & Interfaces | CPU | Dual Cortex‑A17 + Quad Cortex‑A53 |
| GPU | Mali‑T764 | |
| RAM | 2GB | |
| Storage | 16GB eMMC | |
| EEPROM | 32KB | |
| HDMI | 3 × HDMI | |
| USB | 2 × USB 2.0 | |
| TF Card Slot | 1 | |
| RS232 | 1 | |
| RJ45 | 1 | |
| TV‑RF | Supported | |
| YPbPr Input | Supported | |
| CVBS Input/Output | Supported | |
| VGA Input/Output | Supported | |
| Coaxial Output | Supported | |
| Android 5.1 Version (Optional) – Network & 3D Formats | Wi‑Fi | Dual‑Band Wi‑Fi |
| Ethernet | 10/100/1000 Mbps RJ45 | |
| 3G/4G | Not Available | |
| Supported 3D Formats | Side‑by‑Side, Top‑and‑Bottom, 2D+Z | |
| Windows Version (Optional) – System & Hardware | Operating System | Windows 10 |
| CPU | Intel® Core™ i5 7th Generation or Higher | |
| Graphics Card | NVIDIA GTX1050 or Above | |
| Optional GPU Upgrade | GTX1060 / GTX1080 / Quadro P4000 | |
| RAM | DDR3 4GB or Higher | |
| SSD | 256GB Standard (512GB / 1TB Optional) | |
| Video Memory | 2GB or Higher | |
| Windows Version (Optional) – Interfaces & Network | USB | 2 × USB 3.0 + 1 × USB 2.0 Host + 5 × USB |
| HDMI | 1 × HDMI 2.0 | |
| DisplayPort | 1 × DP 1.2 | |
| DVI | 1 × DVI | |
| Audio Output | 3.5mm Audio Jack | |
| Ethernet | Gigabit LAN | |
| Wi‑Fi Chipset | RTL8111F | |
| Multimedia Support | Video Formats | WMV, AVI, FLV, RM, RMVB, MPEG, TS, MP4 |
| Image Formats | BMP, JPEG, PNG, GIF | |
| Supported 3D Formats | Multi‑view, SBS, TAB, 2D+Z, Nine‑Grid 3D (9‑View) | |
Glasses-Free 3D Technology That Captivates Audiences
This Autostereoscopic 3D Display utilizes advanced lenticular lens technology to create realistic depth perception without requiring wearable devices.
Advantages include:
- No glasses required
- Strong depth effect
- Multi-view 3D presentation
- Realistic object visualization
- Enhanced brand storytelling
- Higher audience retention
Modern glasses-free 3D systems can support dozens of viewing perspectives, producing immersive visual effects while minimizing crosstalk and ghosting.
Ideal Applications for Commercial 3D Advertising
The 85 Inch Naked Eye 3D Billboard Display is ideal for:
- Shopping malls
- Luxury retail stores
- Automotive showrooms
- Consumer electronics stores
- Exhibition centers
- Trade shows
- Real estate sales offices
- Airports
- Museums
- Corporate experience centers
Its large screen size and eye-tracking capability make it particularly effective in high-traffic environments where brands need to stand out.
OEM & ODM Custom Manufacturing Services
ZXTLCD specializes in customized 3D display solutions.
Customization options include:
- Custom screen sizes
- Eye-tracking integration
- Touch interaction solutions
- Android system customization
- Industrial PC integration
- Housing design customization
- Logo branding
- Software customization
- CMS integration
- Packaging customization
We support projects from concept development to large-scale mass production.
