Create Immersive Digital Spaces with Ultra-Large Holographic Visualization
As digital display technology evolves, organizations are looking beyond traditional screens to create immersive environments that engage visitors, communicate complex information, and strengthen brand impact.
The 55-inch Light Field Holographic Video Wall 3×3 is engineered to meet these demands. By integrating nine high-performance light field display modules into a unified visual platform, it creates a spectacular large-scale holographic viewing experience that transforms digital content into realistic spatial imagery.
This system is ideal for organizations seeking a signature display solution capable of becoming the centerpiece of any environment.
Massive 3×3 Display Architecture
The 3×3 configuration dramatically expands the display area, creating an enormous visual canvas suitable for presenting large-scale content with exceptional clarity.
Applications include:
- Digital twin platforms
- Urban planning simulations
- Smart manufacturing visualization
- Scientific research presentations
- Interactive exhibition environments
- Corporate innovation showcases
The large display surface allows audiences to view detailed information while maintaining a strong sense of immersion.
| 55-inch naked-eye 3D video wall 3×3 | ||
| General | Product Name | 55″ Naked-eye 3D Video Wall |
| Display Configuration | 3 × 3 (9 Panels) | |
| Display Technology | Naked-eye 3D LCD | |
| Installation | Floor Standing / Wall Mounted | |
| Application | Exhibition Hall, Shopping Mall, Museum, Retail Store, Command Center, Digital Signage | |
| Display | Panel Size | 55 inch |
| Active Display Area (Single Panel) | 1209.6 × 680.4 mm | |
| Resolution (Single Panel) | 1920 × 1080 | |
| Total Resolution | 5760 × 3240 | |
| Aspect Ratio | 16:9 | |
| Pixel Pitch | 0.63 mm | |
| Brightness | 700 cd/m² (Typical) | |
| Contrast Ratio | 1200:1 (Typical) | |
| Viewing Angle | 178° (H) / 178° (V) | |
| Response Time | 8 ms | |
| Refresh Rate | 60 Hz | |
| Display Colors | 16.7 Million | |
| Surface Treatment | Anti-glare | |
| Backlight Type | Direct LED | |
| Bezel Width | Ultra Narrow 3.5 mm (Typical) | |
| 3D Technology | 3D Technology | Glasses-free Lenticular Optical System |
| Viewing Distance | 2.5–8 m (Recommended) | |
| Optimal Viewing Position | Multi-view Zone | |
| System | Operating System | Android / Windows Optional |
| Processor | RK3588 / Intel Optional | |
| RAM | 8GB (Optional) | |
| Storage | 128GB SSD / Flash | |
| Input Interface | HDMI, DP, DVI, USB, RJ45 | |
| Control Method | Network / HDMI / USB | |
| Speaker | Optional | |
| Electrical | Input Voltage | AC 100–240V, 50/60Hz |
| Power Consumption (Single Panel) | ≤180 W | |
| Maximum Power Consumption | ≤1.62 kW | |
| Average Power Consumption | ≈1.0 kW | |
| Frequency | 50/60Hz | |
| Power Supply | Built-in | |
| Standby Power | <0.5W | |
| Protection | Over Voltage / Over Current / Short Circuit | |
| Environmental | Operating Temperature | 0℃ ~ 40℃ |
| Storage Temperature | -20℃ ~ 60℃ | |
| Operating Humidity | 10% ~ 80% RH | |
| Mechanical | Panel Quantity | 9 pcs |
| Arrangement | 3 × 3 | |
| Overall Display Size | 3629 × 2041 mm | |
| Cabinet Depth | 90–120 mm | |
| Cabinet Material | Steel Structure | |
| Frame Color | Black | |
| Net Weight | Approx. 270 kg | |
| Gross Weight | Approx. 330 kg | |
| Package | Packing Method | Wooden Case |
| Transport | Sea / Air | |
| Protection (Packaging) | Shock-proof + Moisture-proof | |
Advanced Light Field Imaging Technology
At the heart of the system is cutting-edge light field technology.
Unlike conventional flat-panel displays, light field visualization reproduces the directional characteristics of light, allowing viewers to perceive natural depth and perspective changes without wearing glasses.
As audiences move through the viewing area, holographic objects appear realistic and continuous, creating a highly engaging visual experience that closely resembles real-world observation.
Professional-Grade Image Quality
The system combines commercial display technology with precision optical engineering.
Key benefits include:
- Ultra-large visual presentation area
- High-resolution image quality
- Realistic holographic depth effects
- Accurate color reproduction
- Smooth motion rendering
- Consistent image performance
These features ensure reliable visual quality in demanding commercial environments.
Flexible Customization and Integration
The modular structure supports flexible deployment across a variety of projects.
Customization options include:
- Display configuration
- Hardware specifications
- Control systems
- Interactive software
- Network integration
- Content management platforms
OEM and ODM services are available for customized project requirements.
Key Features
- 55-inch light field holographic display modules
- 3×3 seamless video wall configuration
- Glasses-free 3D visualization technology
- Ultra-large immersive display platform
- Multi-view holographic experience
- Digital twin visualization compatibility
- Smart city application support
- Commercial-grade reliability
- Flexible system integration
- OEM and ODM customization services
