A Next-Level Immersive Visualization Infrastructure
As digital transformation accelerates across industries, visualization systems are evolving from simple display tools into strategic information platforms.
The 55-inch Light Field Holographic Video Wall 5×5 represents the upper tier of large-format immersive display solutions. By combining twenty-five synchronized light field display modules, it forms an extensive holographic visualization surface capable of delivering highly detailed, spatially accurate 3D content at an unprecedented scale.
This system is designed not just for presentation, but for decision-making, simulation, and immersive communication.
Ultra-Large 5×5 Visualization Matrix
The 5×5 configuration creates a massive display field suitable for complex and data-rich environments.
It is ideal for:
- National and regional command centers
- Smart city integrated management platforms
- Large-scale transportation control rooms
- Industrial digital twin systems
- Aerospace and defense visualization
- Mega exhibition installations
The expanded visual area enables operators and audiences to interpret large-scale systems with improved clarity and spatial understanding.
| General | Product Name | 55″ Glasses-free 3D Video Wall |
| Display Technology | LCD + Lenticular Autostereoscopic 3D | |
| Video Wall Configuration | 5 × 5 | |
| Screen Quantity | 25 Panels | |
| Display Type | Commercial Indoor Digital Signage | |
| Resolution (Single) | 3840 × 2160 (4K UHD) | |
| Total Resolution (5×5)* | 19200 × 10800 (theoretical; actual depends on controller and content resolution) | |
| Aspect Ratio | 16:9 | |
| 3D Technology | Glasses-free Lenticular | |
| Viewing Mode | 2D / 3D Switchable | |
| Number of Views | Up to 54 Views | |
| Best Viewing Distance | 2.5 – 5.0 m | |
| Best Viewing Angle | ±45° | |
| Viewing Angle | 178° (H/V) | |
| Display | Screen Size | 55″ |
| Display Area | 1209.6 × 680.4 mm | |
| Panel Resolution | 3840 × 2160 | |
| Brightness | 500 cd/m² | |
| Contrast Ratio | 4000:1 | |
| Refresh Rate | 60 Hz | |
| Color Depth | 1.07 Billion Colors | |
| Response Time | ≤8 ms | |
| Surface Treatment | Anti-glare | |
| Mechanical | Panel Size (single unit) | 1249 × 749 × 93 mm |
| Display Size (Single) | 1209.6 × 680.4 mm | |
| Installation | Wall-mounted / Video Wall | |
| Cabinet Material | Metal Housing | |
| Panel Weight | 47 kg | |
| Weight with Stand | 50 kg | |
| Video Wall Dimensions (5×5) | Horizontal Panels | 5 |
| Vertical Panels | 5 | |
| Overall Width | 6245 mm | |
| Overall Height | 3745 mm | |
| Overall Depth | 93 mm | |
| Total Display Area | 6048 × 3402 mm | |
| Total Weight | Approx. 1175 kg (without mounting frame) | |
| Note | Overall dimensions are calculated based on single‑unit panel size (1249×749×93 mm), excluding mounting frame and service clearance. | |
| System | Operating System | Android (Optional Windows) |
| CPU | Quad-core Processor | |
| Memory | 1 GB DDR3 | |
| Storage | 8 GB | |
| Input Interface | HDMI ×1, VGA ×1, USB ×1, LAN ×1 | |
| Audio Output | Stereo | |
| Content Support | Image / Video / HTML / CMS | |
| Electrical | Input Voltage | AC 100–240 V, 50/60 Hz |
| Power Consumption (Single) | 85 W | |
| Total Power (25 Panels) | Approx. 2125 W | |
| Standby Power | ≤0.5 W | |
| Environmental | Operating Temperature | 0°C ~ 50°C |
| Storage Temperature | -20°C ~ 60°C | |
| Operating Humidity | 20% ~ 90% RH | |
| Storage Humidity | 10% ~ 90% RH |
Light Field Holography for Real Spatial Perception
Unlike traditional LED or LCD video walls, this system uses advanced light field imaging to reconstruct real optical depth.
Viewers perceive:
- Natural 3D depth without glasses
- Continuous perspective shifts when moving
- Realistic spatial relationships between objects
- Stable multi-view rendering for groups
This creates a highly intuitive way to understand complex systems and environments.
Designed for Mission-Critical Environments
The 5×5 light field video wall is engineered for high-reliability, high-performance environments where accuracy and clarity are essential.
Command & Control Centers
Provide real-time monitoring of large-scale operational systems.
Smart City Operations
Visualize urban infrastructure, traffic flow, and public systems in real time.
Industrial Monitoring Platforms
Support large factory operations and multi-system coordination.
Defense and Emergency Systems
Enable situational awareness with high-level spatial visualization.
Mega Exhibition Spaces
Deliver unforgettable large-scale immersive experiences.
Defining the Future of Large-Scale Visualization
The 55-inch Light Field Holographic Video Wall 5×5 represents a new class of immersive visualization systems that go beyond traditional display technology.
By combining extreme scale, optical precision, and real spatial depth, it enables organizations to transform how they monitor systems, present data, and engage audiences.
From command centers to mega exhibitions, it delivers a powerful platform for the next generation of digital visualization infrastructure.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
